Quick-Reference for Titan / Speeflo PowrTwin 6900 XLT
OEM P/N	Bedford P/N	Description / Reference / Notes
Click on the OEM or Bedford part number links to view the product information pages.
Repair Kits
Displacement Pump (Fluid Section)
143-500	- - -	Major Repair Kit (Includes rod, cylinder & repair kit) - order parts separately
144-050	20-2152	Repair Kit with Leather & Polyethylene Packings
Hydraulic Motor
235-050	20-2439	Hydraulic Motor Repair Kit
Piston Rods
143-117	57-2274	Rod
Cylinders & Sleeves
143-822	57-2329	Cylinder
Carbide Ball Seats, Check Valves & Check Balls
Upper Ball Seat (Outlet Seat)
Outlet Valve with Reversible Seats
236-050	- - -	Piston Valve Assy (housing, cage, ball, seat & seal)
236-012	- - -	Outlet Valve Seat
138-225	9-1183	Piston Ball, stainless steel
236-011	8-2698	Seal, outlet valve seat
236-032	8-2772	Seal, outlet valve seat
Outlet Valve with Soldered Seat
143-945A	58-2327	Piston Valve (outlet valve)
138-225	9-1183	Piston Ball, stainless steel
Lower Ball Seat (Intake Seat)
236-010	- - -	Replaced by 236-010A
236-010A	- - -	Intake Valve Assy (housing, cage, ball, seat & o-ring)
143-026	- - -	Intake Valve Seat
178-700	9-477	Intake Ball, stainless steel
143-025	15-2699	Teflon O-Ring, inlet valve seat
Miscellaneous Fluid Section Repair Parts
138-001	- - -	Spring Retainer, lower
138-153A	20-571	Upper Packing Set with Leather & Polyethylene Packings
138-153A	20-571	Lower Packing Set with Leather & Polyethylene Packings
140-009	0-565	O-Ring, lower cylinder seal, outer
142-003	- - -	Spring, lower packing
142-004	- - -	Spring, upper packing
143-019	10-1849	Retaining Ring, attach pin
143-120	- - -	Connecting Pin, at top of rod
145-031	15-1473	Teflon O-Ring, upper & lower cylinder seal
236-031	- - -	Replaced by 236-031A
236-031A	- - -	Housing, Piston Valve (includes seal)
236-126	- - -	Housing, intake valve
236-141	- - -	Ball Cage, intake valve, lower
451-085	- - -	Ball Cage, piston
Dump Valves, Prime/Spray Valves, Pressure Release Valves, and Components
Complete Assemblies
944-030	- - -	Replaced by 944-030A
944-030A	- - -	Bleed Valve Assembly
944-040	- - -	Bleed Valve Assemby & Drain Tube (also includes elbow fitting)
Repair Kits
944-000	20-2855	Repair Kit, bleed valve (ball, o-rings & seals)
944-043	58-2853	Seat, carbide
Inlet Filters, Suction Hoses/Tubes, Drain Hoses, and Components
103-816	- - -	Siphon Hose Assembly, 1-1/4" OD x 4-1/2'
103-817	- - -	Siphon Hose Assembly, 1-1/4" OD x 6-1/2'
103-627	14-2299	Inlet Filter Assembly, 10 mesh, for 1-1/4" OD tube
Outlet Filter Assembly, Filter Elements & Components
930-515	- - -	Outlet Filter Assembly
930-050	20-2586	Filter Service Kit, 930 Series (includes: spring gaskets & o-ring)
- - - - - - - - - - - - - -
180-909	- - -	Outlet Filter Seat
891-193	15-2589	Teflon O-Ring, outlet filter seat
920-006	6-2063	Teflon Gasket, thick, outlet filter
920-070	6-2064	Teflon Gasket, thin, outlet filter
930-005	14-2344	Outlet Filter Element, 5 Mesh with Check Ball
930-006	14-2346	Outlet Filter Element, 50 Mesh with Check Ball
930-007	14-2347	Outlet Filter Element, 100 Mesh with Check Ball
930-020	23-2588	Spring, fluid outlet filter
930-920	- - -	Bowl, outlet filter assy
930-937	- - -	Cap, outlet filter assy
Titan / Speeflo / Wagner Instruction Manuals
313-2495 A	PowrTwin 6900 XLT
Click Pictures to Enlarge = = = = = = = = = = = = = = = =


Before ordering any repair parts or attempting any maintenance, carefully read all instructions and warnings and verify part numbers required as specified in the OEM manuals that came with your particular unit. This reference was generated on 05/08/2017. Part numbers on this reference were last modified on 09/30/2014.
