Spray Equipment Parts - GPX 1250


Quick-Reference for Wagner SprayTech GPX 1250
OEM P/N	Bedford P/N	Description / Reference / Notes
Click on the OEM or Bedford part number links to view the product information pages.
Repair Kits
Displacement Pump (Fluid Section)
0509510	- - -	Packing Repair Kit
Piston Rods
0509913	- - -	Piston Rod
Cylinders & Sleeves
0509914	- - -	Cylinder
Carbide Ball Seats, Check Valves & Check Balls
Upper Ball Seat (Outlet Seat)
0294516	58-2593	Seat, oulet valve
9841502	9-2591	Ball, outlet valve, 10mm, carbide
Lower Ball Seat (Intake Seat)
00310	58-2778	Seat, intake valve
51519	9-1642	Ball, intake
Miscellaneous Fluid Section Repair Parts
00203	15-1779	Teflon O-Ring, intake seat
0507452	44-2824	Ball Cage, outlet
0507454	8-2819	Washer, nylon, outlet seat
0507728	- - -	Intake Housing, upright models
0507729	- - -	Ball Cage, intake
0507730	0-2978	O-Ring, Viton, intake housing
0507731	6-2979	Backup Ring, Teflon, intake housing
0507733	44-2825	Retainer, outlet valve housing
0507734	8-2821	Seal, outlet valve
0509135	- - -	Piston Assembly, piston rod & outlet valve components
0509505	- - -	Jam Nut, upper, cylinder
0509511	- - -	Lower Support Ring
0509554	- - -	Upper Seal Retainer
0509555	- - -	Spash Guard, plug
0509911	- - -	Lower Packing Assembly
0509912	- - -	Upper Packing Assembly
Dump Valves, Prime/Spray Valves, Pressure Release Valves, and Components
Complete Assembly
0507690	29-2600	Prime / Spray Valve Assembly - Order as: Titan 700-258 or 800-915
700-258	29-2600	Prime / Spray Valve Assembly (Alternate P/N) - with standard Viton o-rings
800-915	29-2835	Prive/Spray Valve Assembly (Alternate P/N) - with solvent resistant o-ring
Components
0507662	- - -	Handle
0507735	- - -	Cam Base
0507736	19-2611	Dowel Pin, cam base
0507741	0-2105	O-Ring, Viton, external
0507742	12-2617	Retaining Nut
0507743	58-2608	Stem Assembly, prime valve
0507744	- - -	Housing, prime valve
0507745	10-2109	Gasket, copper
0507746	- - -	Seat, prime valve
0507747	- - -	Spring
5000529	6-2106	Backup Ring, Teflon
5006543	19-2618	Grooved Pin, handle
5006547	0-2111	O-Ring, Viton, stem
Miscellaneous Parts & Accessories
14068	14-2596	Outlet Filter Element, 100 mesh, solid endcap
14069	14-2595	Outlet Filter Element, 50 mesh, solid endcap
14072	15-2243	Teflon O-Ring, outlet filter
0509180	- - -	Suction Set Assembly, 5 Gallon, 1-5/16" thread
0509185	- - -	Suction Hose Assembly, 5 gallon, 1-5/16" thread
0509542	- - -	Siphon Tube, 1/5/16" thread
0509927	- - -	Lower Packing Insertion Tool
5006536	14-2682	Inlet Filter, 1-5/16" UNF(f), 10 mesh, nylon cap, single sceen
9894245	- - -	Support, outlet filter
Wagner Instruction Manuals
0509812	GPX 1250 Gas Piston Pump
Click Pictures to Enlarge = = = = = = = = = = = = = = = =


Before ordering any repair parts or attempting any maintenance, carefully read all instructions and warnings and verify part numbers required as specified in the OEM manuals that came with your particular unit. This reference was generated on 05/08/2017. Part numbers on this reference were last modified on 03/19/2013.
