Spray Equipment Parts - Corsair


Quick-Reference for Wagner SprayTech / Amspray Corsair
OEM P/N	Bedford P/N	Description / Reference / Notes
Click on the OEM or Bedford part number links to view the product information pages.
Repair Kits
Displacement Pump (Fluid Section)
For Non-Sleeved 1-Piece Cylinder Pumps (Model 396 Fluid Section):
04235	20-1783	Repair Kit with Leather & Polyethylene Packings
04243	- - -	Replaced by 4235
04245	- - -	Replaced by 4235
05568	20-1511	Repair Kit with Teflon Packings
For "Excel Series" Removable-Sleeved Cylinder Pumps (Model 296 Fluid Section):
04235	20-1783	Repair Kit with Leather & Polyethylene Packings
04243	- - -	Replaced by 4235
04245	- - -	Replaced by 4235
05568	20-1511	Repair Kit with Teflon Packings
For "Planotronic Series" Stationary Packing Pumps
13292	20-1886	Repair Kit with Leather & Polyethylene Packings
13592	- - -	Replace by 13292
Piston Rods
For Non-Sleeved 1-Piece Cylinder Pumps (Model 396 Fluid Section):
00181	- - -	Piston Rod - Chrome Plated Stainless Steel
00191	57-1391	Piston Rod - Stainless Steel
For "Excel Series" Removable-Sleeved Cylinder Pumps (Model 296 Fluid Section):
00181	- - -	Piston Rod - Chrome Plated Stainless Steel
For "Planotronic Series" Stationary Packing Pumps
13553	- - -	Piston Rod
Cylinders & Sleeves
For Non-Sleeved 1-Piece Cylinder Pumps (Model 396 Fluid Section):
00299	57-1431	Cylinder, non-sleeved
For "Excel Series" Removable-Sleeved Cylinder Pumps (Model 296 Fluid Section):
00280	- - -	Cylinder, out casing for sleeve
00289	- - -	Sleeve
For "Planotronic Series" Stationary Packing Pumps
13405	- - -	Cylinder
Carbide Ball Seats, Check Valves & Check Balls
Upper Ball Seat (Outlet Seat)
For Non-Sleeved 1-Piece Cylinder Pumps (Model 396 Fluid Section):
00159	- - -	Replaced by 186
00186	58-1737	Piston Valve
50164	9-1640	Ball, outlet
For "Excel Series" Removable-Sleeved Cylinder Pumps (Model 296 Fluid Section):
00159	- - -	Replaced by 186
00186	58-1737	Piston Valve
50164	9-1640	Ball, outlet
For "Planotronic Series" Stationary Packing Pumps
13359	58-2791	Seat, outlet
50164	9-1640	Ball, outlet
Lower Ball Seat (Intake Seat)
For Non-Sleeved 1-Piece Cylinder Pumps (Model 396 Fluid Section):
00205	58-1709	Intake Valve
50172	9-1641	Ball, intake
For "Excel Series" Removable-Sleeved Cylinder Pumps (Model 296 Fluid Section):
13363	- - -	Intake (Foot) Valve
50172	9-1641	Ball, intake
For "Planotronic Series" Stationary Packing Pumps
00310	58-2778	Seat, intake valve
51519	9-1642	Ball, intake
Miscellaneous Fluid Section Repair Parts
For Non-Sleeved 1-Piece Cylinder Pumps (Model 396 Fluid Section):
00035	- - -	Upper Packing Nut
00094	19-2655	Jam Nut, piston valve
00248	10-1671	Copper Gasket, intake valve
00256	- - -	Ball Cage, intake
00264	19-1513	Ball Stop Pin, intake
00302	- - -	Upper Lock Nut
For "Excel Series" Removable-Sleeved Cylinder Pumps (Model 296 Fluid Section):
00035	- - -	Upper Packing Nut
00094	19-2655	Jam Nut, piston valve
00212	- - -	Ball Stop Disc, intake valve
00214	- - -	Intake (Foot) Valve Housing
00215	15-1532	Teflon O-Ring, at top & bottom of sleeve
00302	- - -	Upper Lock Nut
13367	0-1535	O-Ring, intake valve
13379	- - -	Ball Cage, intake
For "Planotronic Series" Stationary Packing Pumps
00203	15-1779	Teflon O-Ring, intake seat
00302	- - -	Upper Lock Nut
00311	- - -	Ball Cage, inlet
00361	- - -	Upper Packing Nut
09446	10-1882	Washer, crush, outlet seat
13357	- - -	Ball Cage, outlet
13380	- - -	Ball Stop, inlet
13403	- - -	Housing, inlet valve
13458	- - -	Ball Stop, outlet
13481	12-2766	Retainer, Piston Seat
13482	- - -	Jam Nut, outlet retainer
Miscellaneous Parts & Accessories
02208	- - -	Pressure Transducer Assembly
02283	- - -	Pressure Transducer Packing Kit
02941	- - -	Suction Tube, 1/2" NPT
02968	- - -	Adapter, inlet strainer
02975	14-1325	Inlet Filter, 3/4" NPT(f), 8 mesh, stainless steel, single screen
02976	14-1329	Inlet Filter, 3/4" NPT(f), 16 mesh, stainless steel, double sceen
04339	14-1489	Outlet Filter Element, 50 Mesh, with hole in endcap
04340	14-1490	Outlet Filter Element, 100 Mesh, with hole in endcap
13463	- - -	Suction Tube, 3/4" NPT
14066	- - -	Support, outlet filter
14068	14-2596	Outlet Filter Element, 100 mesh, solid endcap
14069	14-2595	Outlet Filter Element, 50 mesh, solid endcap
14072	15-2243	Teflon O-Ring, outlet filter
60003	- - -	Suction Tube, 3/4" NPT, 9-3/8" long
Amspray Service Bulletins
49088	Corsair & Avenger Excell Series Airless Sprayer
40296	Fluid Section Assembly #00296
Click Pictures to Enlarge = = = = = = = = = = = = = = = =


Before ordering any repair parts or attempting any maintenance, carefully read all instructions and warnings and verify part numbers required as specified in the OEM manuals that came with your particular unit. This reference was generated on 05/08/2017. Part numbers on this reference were last modified on 05/21/2003.
