Spray Equipment Parts - 85 SE


Quick-Reference for HERO 85 SE
OEM P/N	Bedford P/N	Description / Reference / Notes
Click on the OEM or Bedford part number links to view the product information pages.
Repair Kits
Fluid Section
4-606RK	20-2538	Bleed Valve Repair Kit
4-6654	20-1723	Outgo Repair Kit
4-6655	20-1724	Outgo Overhaul Kit (Repair Kit with Seat)
4-6658B	- - -	Intake Repair Kit (copper gasket under seat)
4-6659B	- - -	Intake Overhaul Kit, includes seat (copper gasket under seat)
Hydraulic Section
4-04-22-4500	- - -	Hydrapulse Membrane, diaphragm (Lifetime Warrantee)
4-27CRK	- - -	Hydraulic Repair Kit
Intake Section Repair Parts
02-22-2001	- - -	Ball Stop
02-22-2002	- - -	Ball Guide
02-22-2005	- - -	Spring
02-22-2006	0-2003	O-Ring, urethane
02-22-2009	10-2005	Crush Washer
4-02-22-2501	- - -	Head, Hydrapulse Gold
4-02-22-2502	- - -	Endcap, Hydrapulse Gold (o-ring under seat)
3	- - -	Capscrew, Socket Head, 5/16" x 1-3/4"
5V	0-1589	O-Ring, Viton
6	58-1645	Seat, 3/4", Carbide
17S	9-1595	Ball, 3/4", Corrsion Resistant
Outgo Section Repair Parts
4-11A	- - -	Outgo Valve (Complete)
7C	10-1590	Copper Crush Washer
11A-1	- - -	Lower Valve Body
11A-2	- - -	Upper Valve Body
11A-3CP	10-1591	Copper Crush Washer
11A-4	58-1670	Seat, 3/8", Carbide
11A-5	9-1592	Ball, 3/8", Nylon
11A-5S	9-1593	Ball, ,3/8", stainless steel (optional)
11A-6	17-1705	Cage
11A-7	23-1600	Spring
Hydraulic Section Repair Parts
4-04-22-4500	- - -	Hydrapulse Membrane, diaphragm (Lifetime Warrantee)
4-38A-2	- - -	Rod, piston
4-37A/150	- - -	Seal Set, piston
4-38A/150-1	- - -	Piston
38A-3	- - -	Seat, piston
Miscellaneous Parts & Accessories
3-WHIPEND	13-792	3/16" x 3' Airless Hose Assembly
4-02-85-2500	- - -	Siphon Hose Assembly (Complete)
4-02-250-2516	- - -	Siphon Hose, 42"
4-606	- - -	Bleed Valve (Complete)
4-606RK	20-2538	Bleed Valve Repair Kit
114	13-932	1/4" x 50' Airless Hose Assembly
115	13-931	1/4" x 25' Airless Hose Assembly
117	13-453	3/8" x 50' Airless Hose Assembly
187A	14-2332	Inlet Filter, 3/4" NPT(f), 16 mesh, stainless steel, double screen
Click Pictures to Enlarge = = = = = = = = = = = = = = = =


Before ordering any repair parts or attempting any maintenance, carefully read all instructions and warnings and verify part numbers required as specified in the OEM manuals that came with your particular unit. This reference was generated on 05/08/2017. Part numbers on this reference were last modified on 12/09/2005.
